Deskripsi Produk
RECEIVER:
- Frequency range:470-862MHz
- On icy rao:40.83 For free selection, Multi-function LCD display
- ACT/IR function
- With PLL combined technology
- Frequency stability: + 0.002%
- Frequency response: 40-18000Hz
- S/N ratio:105dB(12dB S/N AD)
- T.H.D: <0.5% @1KHz
- Mute mode:Noise locked+pilot tone locked
- Sensitivity:30V 30Db S/N
- Max. Deviation Range: +2KHz
- Image rejection:>90dB typical
- Adjacent channel rejection:90dB typical
- Spurious Emissions:<-60dB
- Max. Output Level: Balance:0-600m V, Unbalance:0-300m V
- Power Supply: 230V,50-60Hz
- Power consumption:5W
- Working Temperateure:-10 °C to 40°C
MICROPHONE CONFERENCE:
- Frequency range:470-862MHz
- Band width: 200 channels for free selection
- ACT/IR function, With multi-function LCD digital display With
- PLL combined technology Max Deviation Range: UHF +45KHz
- Frequency stability:#0.002%
- Transmitter Power: (H)10dBm, (L)5dBm
- S/N ratio:>105dB(12dB S/N AD)
- T.H.D.<0.5% @ 1KHz
- Audio output voltage:-12dB
- Input power voltage: DC 13.5V, 1200mA
- Battery type:2* AA 1.5V Alkaline battery
- Operating time:More than 6h
