Deskripsi Produk
| Model: ETM105W-D |
| Max Load Capacity: 100 kN |
| Load Cell Type: Universal strain-gage load cell (tension & compression) |
| Load Accuracy: Class 0.5 (ISO 7500-1 / ASTM E4) |
| Force Measurement Range: 0.4% – 100% F.S |
| Force Indicating Error: ≤ ±0.5% |
| Load Resolution: Capacity / 500,000 |
| Deformation Measuring Range: 0.2% – 100% F.S |
| Deformation Accuracy: ≤ ±0.5% |
| Deformation Rate Adjustment Range: 0.02 – 5% F.S |
| Displacement Accuracy: ≤ ±0.5% |
| Displacement Resolution: 0.04 μm |
| Force Control Rate Range: 0.001% – 5% F.S/s |
| Force Control Accuracy: ±2% (<0.05%FS/s), ±0.5% (≥0.05%FS/s) |
| Deformation Control Rate Range: 0.005 – 5% F.S/s |
| Crosshead Speed Range: 0.001 – 500 mm/min |
| Crosshead Speed Accuracy: ≤ ±0.5% |
| Crosshead Travel (Testing Space): 1085 mm |
| Max Tensile Testing Space: 650 mm |
| Max Compression Testing Space: 1000 mm |
| Test Width: 500 mm |
| Power Supply: 1 kW, AC 220V ±10%, 50/60 Hz |
